CNC Hydraulic Press Brake

ESA-S630 features

Graphic color 10" touch screen display (1024 x 600 pixels resolution).

128 MB silicon disk.

Interactive 2d graphic editor for work-pieces and tools data entry

2D graphic display of machine frame, work-piece and tools

Manual 2D graphic identification of the best bending sequence(option)

4  fast  counting  circuits  for  line  drive  0-5Vdc  differential encoder  or npn/push pull. The encoders are powered at 5Vdc (max 200mA per channel).

4 analog outputs(±10V) with 13bits + sign resolution.

4 digital inputs for the zero micros.

4 analog inputs, 12 bits resolution, ranges 0÷10V, 0÷5V.

2 general purposes analog outputs, 0÷10V (8 bits resolution).

32 digital inputs (24Vdc).

32 digital outputs (24Vdc, 0,7A max.) protected against overload and short-circuits.

2 serial port rs232.

1 Can port with 9 pins subd f connector.

1 Ethernet port 10/100 Mbit (lan connection)

1 VGA port for external monitor connection

2 USB (2.0) ports.

24Vdc power supply.
